When your medical device delivers a misdiagnosis due to counter signal delays, or an industrial controller crashes unexpectedly at –40°C, the 74HC4017D,653 could be either a lifesaver—or the starting point of a disaster. With over 200 million units of this 83 MHz decade counter consumed annually worldwide, it surged to 231 in Q2 2025 about 22% above the industry average. In this comprehensive article, we'll delve into the intricacies of the 74HC4017D,653, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
74
HC4017D,653's Overview
The 74HC4017D,653 is a single 5-bit decade counter with ten fully decoded outputs and one input for clock signals. It counts from 0 to 9 in a sequential manner on each clock pulse and resets once the count completes. It is designed using high-speed CMOS technology, delivering fast performance and superior noise immunity.
Key Features
Let's delve into the standout features that make the 74HC4017D,653 a standout in the world of electronics:
· The IC functions as a decade up counter.
· It contains 10 individual outputs per counting cycle.
· It supports both positive-edge and negative-edge triggering.
· It is manufactured using CMOS process technology.
· The output type is push-pull, supporting direct drive of LEDs or digital loads.
· It offers an asynchronous reset function for flexible control.
· The device is uni-directional and does not support down counting.
· It is surface-mount compatible with SO-16 packaging.
· Low quiescent current ensures low-power operation.
· Wide operating voltage range from 2V to 6V supports a variety of applications.
· The maximum propagation delay is as low as 43ns at 6V, enabling high-speed operations.
· The part is available in tape and reel packaging, ideal for automated assembly.
Get more details: 74HC4017D,653: Features, Specs & More
When your medical device delivers a misdiagnosis due to counter signal delays, or an industrial controller crashes unexpectedly at –40°C, the 74HC4017D,653 could be either a lifesaver—or the starting ...
In the fast-evolving world of embedded systems and digital design, compact yet powerful FPGAs are essential for developers seeking high performance within tight design constraints. One such solution is the Lattice Semiconductor LCMXO256C-3TN100I—a small-footprint, low-power, high-reliability FPGA from the popular MachXO family. In this comprehensive article, we'll delve into the intricacies of the LCMXO256C-3TN100I, uncovering its definition, key features, specifications, applications, and a closer look at its manufacturer.
LCMXO256C-3TN100I's Overview
The LCMXO256C-3TN100I is a Field-Programmable Gate Array (FPGA) developed by Lattice Semiconductor, designed using a 130nm CMOS process. It belongs to the MachXO family, which is known for offering non-volatile, low-cost, and instant-on programmable logic devices. This model features 256 logic elements and supports various I/O standards with versatile voltage options. It's particularly tailored for industrial-grade applications, operating effectively in temperatures ranging from -40°C to 100°C.
Key Features
Let's delve into the standout features that make the LCMXO256C-3TN100I a standout in the world of electronics:
· Based on 130nm process technology for optimized performance and low power.
· Supports 1.8V, 2.5V, and 3.3V operating supply voltages.
· Includes 256 logic elements, suitable for small-to-medium logic designs.
· Offers 78 user-configurable I/O pins to interface with other hardware.
· Equipped with 2 I/O banks and a wide range of I/O voltage support (1.2V to 3.3V).
· Features in-system programmability (ISP) and reprogrammability for design flexibility.
· Integrates 8 global clocks for better timing and synchronization.
· Built with 2048 bits of distributed RAM for efficient data handling.
· Low maximum propagation delay time of 4.9ns.
· Comes in a 100-pin TQFP package with a compact 14x14mm footprint.
Get more details: LCMXO256C-3TN100I: Features, Specs & More
In the fast-evolving world of embedded systems and digital design, compact yet powerful FPGAs are essential for developers seeking high performance within tight design constraints. One such solution i...
